Super Alloy Monel 400 Round Bar UNS N04400 B164 Monel 400 Astm Standard
| Place of Origin | CHINA |
|---|---|
| Brand Name | DM |
| Certification | PED |
| Model Number | Alloy Steel Round bar |
| Minimum Order Quantity | 1Ton |
| Price | 600-1000USD |
| Packaging Details | seaworth plywood case |
| Delivery Time | 3weeks |
| Payment Terms | L/C, T/T |
| Supply Ability | 1000Ton per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Stainless Steel | Process | Forging Hot Rolling |
|---|---|---|---|
| Heat Treatment | Solution Normal And Temper | Smelting Process | Vacuum Degassing With Fine Grained |
| Test | Chemical Analysis, Mechanical Test UT Test | Surface | Black Or Peeled And Polished |
| Dimensions | 8-480mm | ||
| High Light | Super Alloy Monel 400 Round Bar,N04400 Monel 400 Round Bar,B164 Monel 400 Astm Standard |
||
Product Description
Product Description
Customized Special Steel Nickel Alloy Super Alloy Monel 400 ASTM B164 UNS N04400 Round Bar
Monel 400
Monel 400 material is a nickel-copper alloy (about 67% Ni – 23% Cu) that is resistant to sea water and steam at high temperatures as well as to salt and caustic solutions. Alloy 400 is a solid solution alloy that can only be hardened by cold working. This nickel alloy exhibits characteristics like good corrosion resistance, good weldability and high strength. A low corrosion rate in rapidly flowing brackish or seawater combined with excellent resistance to stress-corrosion cracking in most freshwaters, and its resistance to a variety of corrosive conditions led to its wide use in marine applications and other non-oxidizing chloride solutions. This nickel alloy is particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated. As would be expected from its high copper content, alloy 400 is rapidly attacked by nitric acid and ammonia systems.
Chemical Composition %
Monel K-500
Monel K500 material is a nickel-copper alloy that combines the excellent corrosion resistance characteristic of Monel 400 with the added advantage of greater strength and hardness. These amplified properties, strength and hardness, are obtained by adding aluminum and titanium to the nickel-copper base and by a thermal processing used to effect precipitation, typically called age hardening or aging. When in the age-hardened condition, Monel K-500 has a greater tendency toward stress-corrosion cracking in some environments than Monel 400. Alloy K-500 has approximately three times the yield strength and double the tensile strength when compared with alloy 400. Plus, it can be further strengthened by cold working prior to precipitation hardening. The strength of this nickel steel alloy is maintained to 1200° F but stays ductile and tough down to temperatures of 400° F. Its melting range is 2400-2460° F.
Chemical Composition, %
Within Drachma’s product scope, we offer a complete range of steel and metals starting from carbon and low alloyed steels to nickel based steels and metals such as aluminum, bronze and titanium. We deliver your product directly from stock or manufacture it according to your specification and drawing and in accordance with the required manufacturing norm, for example EN or ASTM/ASME and PED 2014/68/EU.
We deliver products compliant to industrial standards and our customers’ requirments related to product certification.
Detailed Images
Company Profile
DRACHMA (ZHANGJIAGANG) MATERIAL CO.LTD has two main production plants. Zhangjiagang plant is responsible for the rough forming of workpieces, mainly forging process; While Hangzhou plant is mainly responsible for precision machining, welding and inspection of products. We implement this layout mainly to use the industrial advantages of each region to achieve maximum economic benefits.
Traditional processing enterprises often do not have such ability, the lack of blank forming ability is unable to achieve the optimal use of materials, resulting in excessive processing allowance, long cycle, high cost. Zhangjiagang is located in the southern jiangsu province, which has the strongest forging capacity in China. It has a good supporting industry and can realize the diversified production of forging and pressing blanks. Thanks to this, the product cycle of our company is faster, the cost performance is higher, and the forging products have better mechanical properties than the products directly processed by rod or plate.
In addition, our company has strong welding ability, which can weld and assemble parts to achieve system delivery. We adopt the mode of automatic robot welding and manual precision welding to achieve flexibility and high quality.
| Total Production (Tons) | 2018 | 2019 | 2020 |
| SS Flange | 300 | 350 | 400 |
| Duplex Flange | 100 | 120 | 180 |
| Alloy Steel Flange | 90 | 110 | 140 |
| Non-Standard parts | 150 | 180 | 230 |
No. of employee: Production administration 15 person; Workshop 120 person; Quality and Technical 15 person.
Main Market: Europe, America, East south Asia, Korea, Japan
Management System: IS09001
Sawing Machining: 6 sets
Forging Workshop: 2 tons Hammer: 3 sets,
Machining Workshop: CNC Machine 10 sets, CNC drilling 1 set. Common Machining 20 sets, drilling: 7 sets.
Equipment List
| Name | Type | Quantity | Processing range | Precision(um) |
| CNC | MAZAK(QTN350L) | 1 | φ720*1250 | 3 |
| CNC | MAZAK(QTN250L) | 1 | φ580*1500 | 3 |
| Turn milling center | MAZAK(QTN250M) | 2 | φ580*600 | 3 |
| CNC | Newway(NL-634SC) | 1 | φ630*1000 | 5 |
| CNC | FUJI(TN-36) | 2 | φ350*290 | 3 |
| CNC | HAAS SL30 | 1 | φ620*750 | 3 |
| CNC | MAZAK FJV200 | 1 | 560X*410Y*560Z | 3 |
| CNC | LGMAZAK NEXUS160AN-2PC | 1 | 560X*410Y*660Z | 10 |
| CNC | WHEELEL | 2 | 560X*410Y*660Z | 5 |
| Welding | Miller | 1 |
Material List we can deal
Stainless steel :304/1.4307 316/1.4404 321/1.4541 316Ti/1.4571 317L 904L F44 NO6625 UNS718
440A/B/C 431 446 F6a
Carbon Steel:A105, SA350 LF1, LF2, LF3, LF6, A707, A694, 4130, 4140, 8620, 8630, A182F5, F11, F12, F22, F91, F92
Duplex steel : F51 F60 F53 F55
Alloy Steel:4130, 4140, 4142, 4145, 4150, 4320, 4330, 4340, 4350, 4620, 4820, 6150, 8620, 8630, 8822, 9310, 52100, HY80, HY100, 9315, 300M, Nitralloy 135M, 17-22A
Aluminum : 2014, 2024, 2025, 2219, 2618, 3003, 5083, 6061, 7049, 7050, 7075, 7079, 7149, 7150, and 7175
